Options Working procedures Additional settings Prerequisites
Change track line
Start the recording of the
selected
track line or opens
the menu where track lines
can be loaded.
"Measure":
Select track line: The
menu for selecting a
track line will be opened
Create track line: The
menu for creating a
track line will be opened
"Create
name for track
line":
"Standard": The new job
is given the date and
the time of creation as a
name.
"User-defined": Another
setting will be shown. A
user-defined name can
be given.
"Prompt": When the job
is created, a text box is
opened in which the
name must be entered.
Under "Adjust track
guidance
mode", A-B line,
identical curves or circular
track is selected.
Hide on success
The quick-start info will be
automatically
closed when
the work procedure has
been successfully
completed.
"Measure":
Select track line: The
menu for selecting a
track line will be opened
Create track line: The
menu for creating a
track line will be opened
"Create
name for track
line":
"Standard": The new job
is given the date and
the time of creation as a
name.
"User-defined": Another
setting will be shown. A
user-defined name can
be given.
"Prompt": When the job
is created, a text box is
opened in which the
name must be entered.
None
Configuring the "Change job" option
1. Enable the option with "Option status".
048269
F | Configuring the AMAPAD | Entering the system settings
MG5574-EN-II | B.1 | 25.10.2016
50
