Communication Settings

130

NetLinx Studio - Instruction Manual

4. In the Available Connections window, select the IP Address of the Virtual NetLinx Master.

5. Click Select - note that this updates the Current Platform Transport Selected field with the IP address of the

selected virtual Master.

6. Click OK to close the Communication Settings dialog and return to the Master Communication Settings dialog,

now indicating the selected Virtual NetLinx Master as the current connection (FIG. 206).

FIG. 205 Communication Settings dialog - Virtual NetLinx Master communications options

Communication Settings dialog - Virtual NetLinx Master Options

Master System Number: Enter the System Number for the Virtual NetLinx Master.

• Default = 1.

• Range = 1-65535

Assuming that the actual NetLinx Master is set to 0 (via the System Properties dialog -

System ID field), this default setting will work. However, if you have designated any other

number as the System ID, be sure to set this System Number to a different number than the

System ID, to avoid a conflict with the actual NetLinx Master.

Note: Changes made to the Master System Number field will not take effect until all

communications are stopped and restarted.

Current Connection: The current connection information (IP Address) is displayed here (read-only)

Available Connections: A listing of available Virtual NetLinx Master connections is provided in this table.

Click on a connection in this list and click Select to set that connection as the current Virtual

NetLinx Master connection.

OK: Click to save your changes and close this dialog.

Cancel: Click to discard your changes and close this dialog.
