Working with System Files

NetLinx Studio - Instruction Manual

Working with Source Code Files

You can create new Source Code files in NetLinx Studio, or add existing Source Code files to a System. Source Code

files are created and/or edited in the Editor windows. Source Code files are stored in the Source folder in the Workspace

tab of the Workspace Bar (FIG. 60).

NetLinx Studio distinguishes between two types of Source Code files; the Master Source Code file and System Source

Code files:

Master Source Code file - The Source Code that is sent to an Axcess or NetLinx Master. The Master Source

Code file defines all of the devices in the System and sets any global parameters for the System.

Source Code files - Axcess or NetLinx Source Code files that are sent to specific NetLinx or Axcess devices

on the bus. You can have as many Source Code files in the Source Code System folder as is required for the

System.

Source Code files are stored in the Source folder (in the Workspace tab of the Workspace Bar).

Creating a New Source Code File

To create a new Source Code file (that is not associated with a System).

1. Click File > New, and select Source File in the New dialog (FIG. 61).

2. Click OK to close this dialog and open the File Template dialog (FIG. 62).

3. Select Yes (default) or No, and click Next to proceed:

FIG. 60 Workspace tab - Source Folder

FIG. 61 New dialog

FIG. 62 File Template dialog
