Working with System Files
62
NetLinx Studio - Instruction Manual
Adding an Existing IR File to a System
To add an existing IR file to a selected System in the current Workspace:
1. Click to select (highlight) a System (in the Workspace tab of the Workspace Bar).
2. Right-click on the IR folder to access the IR File Folder context menu, and select Add Existing IR File (FIG. 119).
3. In the Add Existing IR File dialog, locate and select the IR (.irl or .irv) file that you want to add to the selected
System (FIG. 120).
4. Click Open to access the File Properties dialog, where you can view/edit general file information for the selected
file.
5. Edit the file information (if necessary).
For instructions on using IREdit to view and edit IR files, refer to the IREdit on-line
help.
FIG. 119 IR Folder Context Menu
FIG. 120 Add Existing IR File dialog
Use the Recent tab to quickly access recently used files.
If you select multiple files to add to the System, the program will prompt you to edit
the file properties for each file before adding them.
