Working with System Files
49
NetLinx Studio - Instruction Manual
5. Click OK to add the file to the selected System.
The file should now appear in the Include folder under the selected System. Double-click to open the file in an Editor
window (FIG. 85).
Working with Block Files
Block Files (*.axb) represent blocks of re-usable code. Block files are saved in the Source folder, and can be referenced
in the main Source Code (FIG. 90).
Creating a New Block File
To create a new Block file (that is not associated with a System).
1. Select New from the File menu to open the New dialog (FIG. 91).
2. Select Block File and click OK to open the New Block File dialog (FIG. 92).
If you select multiple files to add to the System, the program will prompt you to edit
the file properties for each file before adding them.
FIG. 89 Workspace tab - Include File Added
FIG. 90 Workspace tab - Block File
FIG. 91 New dialog - Block File selected
FIG. 92 New Block File dialog
