Working with System Files

NetLinx Studio - Instruction Manual

3. In the Add Existing User Interface File dialog, locate and select the UI (.tpd, TP4 or .kpd) file that you want to add

to the selected System (FIG. 116).

.tpd = Touch panel UI files created in TPDesign3

.tp4 = Touch panel UI files created in TPDesign4

.kpd = Keypad UI files created in KPDesign

4. Click Open to access the File Properties dialog where you can view/edit general file information for the selected

file (FIG. 117).

FIG. 115 User Interface Folder Context Menu

FIG. 116 Add Existing User Interface File dialog

Use the Recent tab to quickly access recently used files.

FIG. 117 File Properties dialog
