Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
8 - Coupling Rod
Removing and Instal‐
ling, refer to ⇒ “2.6 Coupling Rod, Removing and Installing”, page 135 .
Note
The aluminum coupling rod has
been replaced with a steel one. Do
not install both types together.
9 - Stabilizer Bar
Removing and Installing, refer to ⇒ “2.5 Stabilizer Bar, Removing and Installing”, page 133 .
10 - Self-Locking Nut
100 Nm
Always replace if removed.
11 - Bolt
90 Nm + 120°
Always replace if removed.
4.2 Air Suspension Strut, Removing and In‐
stalling
Special tools and workshop equipment required
Torque Wrench 1332 40-200Nm - VAG1332-
Air Line Insert Tool - T10212-
Wood block (hardwood) 30 x 50 x 1300 mm
Removing
Caution
During assembly work, ensure no pressure points are cre‐
ated on suspension strut (air suspension) boot.
With vehicles with air suspension, place vehicle on hoist, refer
to ⇒ “4 Positioning Vehicle on Hoist and Wheels”, page 10 .
Remove wheel.
Insert wood block between underbody -Arrow A- and upper
rear control arm -Arrow B-.
Wood block is needed to press wheel bearing housing down.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
146 Rep. Gr.42 - Rear Suspension
