– Support lower control arm with Tensioner Hooks (2 pc.) -
VW552- and Tensioning Strap - T10038- .
– Install Engine/Gearbox Jack - VAG1383A- with Engine/Gear‐
box Jack Adapter - Wheel Hub Support - T10149- .
– Remove screws -1- to -3- and mounting bracket.
Installing
Installation is the reverse of removal, with special attention to the
following:
Tightening specifications, refer to
⇒ “3.1 Coil Spring Suspension Strut, Upper Control Arm, Mount‐
ing Bracket, and Level Control System Sensor Overview”,
page 46
– Suspension strut, installing, refer to
⇒ “3.2 Coil Spring Suspension Strut, Removing and Installing”,
page 48 .
– Install plenum chamber cover, refer to ⇒ Rep. Gr. 50 .
3.7 Level Control System Sensor, Remov‐
ing and Installing
– Level control system sensor, Removing and Installing, refer to
⇒ “3.2 Left Front Level Control System Sensor G78 and Right
Front Level Control Sensor G289 , Removing and Installing”,
page 216 .
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
56 Rep. Gr.40 - Front Suspension
