❑ Servotronic Solenoid Valve - N119- , Removing and Installing
⇒ “3.6 Servotronic Solenoid Valve N119 , Removing and Installing”, page 303 .
7 - Subframe
❑ Removing and Installing, refer to ⇒ “2.2 Subframe, Removing and Installing”, page 125 .
8 - Bolt
❑ Always replace if removed.
9 - Nut
❑ 90 Nm + 90°
❑ Self-locking
❑ Always replace if removed.
10 - Nut
❑ 90 Nm
❑ Self-locking
❑ Always replace if removed.
11 - Wheel Bearing Housing
❑ Tapered holes must be free of oil and grease.
❑ If necessary, clean with a dry rag, do not use cleaning solvent.
❑ Removing and Installing, refer to ⇒ “6.2 Wheel Bearing Housing, Removing and Installing”, page 170 .
12 - Pressure Line
13 - Bolt
❑ 9 Nm
14 - Return Line
15 - Union Nut
❑ 32 Nm
16 - Seal
❑ Always replace.
3.2 Power Steering Gear, Removing and In‐
stalling
Special tools and workshop equipment required
♦ Hose Clamps - Up To 25mm - 3094-
♦ Torque Wrench 1331 5-50Nm - VAG1331-
♦ Torque Wrench 1331 Insert - Open Jaw - 17mm - VAG1331/6-
♦ Torque Wrench 1332 40-200Nm - VAG1332-
♦ Engine/Gearbox Jack - VAG1383A-
♦ Subframe Support - T10031-
♦ -Vehicle Diagnostic Tester-
♦ Puller - Ball Joint - T10187-
♦ Wood block
Removing
Note
In order to remove steering gear, rear subframe must be un‐
screwed and supported.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
3. Steering Gear 293
