Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
9 - Check rear axle camber and adjust if necessary, refer to
⇒ “5.14 Rear Axle Camber, Adjusting”, page 255 .
10 - Check rear axle toe and adjust if necessary, refer to
⇒ “5.15 Rear Axle Toe, Adjusting”, page 255 .
11 - Check front axle toe angle again and adjust if necessary, refer
to
⇒ “5.16 Front Axle Toe Angle, Checking and Adjusting”,
page 255 .
12 - If adjustments have been made on the rear axle, ACC ad‐
justment is required, refer to
⇒ “6 Adaptive Cruise Control”, page 256 .
13 - If the rear axle adjustments have been changed, then is it
necessary to calibrate the lane assist, refer to
⇒ “7.2 Calibration Procedure”, page 271
14 - If adjustments have been made on the suspension, perform
a zero adjustment on the Steering Angle Sensor - G85- using the
-Vehicle Diagnostic Tester- .
5.8 Steering Rack, Checking Center Posi‐
tion
Perform steering centering based on instructions from align‐
ment computer.
Check to ensure that the steering wheel is positioned as hor‐
izontally as possible on the steering column when the wheels
are in the “straight ahead” position.
Reposition steering wheel if necessary.
Otherwise centering of toothed shaft cannot be guaranteed!
If steering wheel was repositioned, zero adjustment must be per‐
formed on the Steering Angle Sensor - G85- . -Vehicle Diagnostic
Tester- .
5.9 Axle Alignment Control Position on Ve‐
hicles with Air Suspension, Checking
Axle Alignment Control Position, Checking
Connect -Vehicle Diagnostic Tester- and then perform vehicle-
specific entry into Guided Fault Finding and select Go To
button “function/component selection”, refer to
⇒ “2.6 Vehicle Diagnostic Tester , Connecting and Selecting
Functions”, page 211 .
Then
“Chassis (Repair group 01; 40 - 49)”
“34 - Level control (Repair group 01: 43, 44)”.
“44 - Wheels, tires, vehicle alignment”.
“KD44 85 - Axle alignment”.
Chassis 1BK/2MB
Front height dimension: 449 mm
Rear height dimension: 465 mm
Height Dimension -x-, Determining
Height dimension -x- is the measurement in mm between center
of wheel and lower edge of fender.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
252 Rep. Gr.44 - Wheels, Tires, Wheel Alignment
