Note
The aluminum coupling rod has
been replaced with a steel one. Do
not install both types together.
10 - Stabilizer Bar
Removing and Installing, refer to ⇒ “2.5 Stabilizer Bar, Removing and Installing”, page 133 .
11 - Self-Locking Nut
100 Nm
Always replace if removed.
12 - Bolt
90 Nm + 120°
Always replace if removed.
5.2 Coil Spring Suspension Strut, Removing
and Installing
Special tools and workshop equipment required
Torque Wrench 1332 40-200Nm - VAG1332-
Wood block (hardwood) 30 x 50 x 1300 mm
Removing
With vehicles with air suspension, place vehicle on hoist, refer
to ⇒ “4 Positioning Vehicle on Hoist and Wheels”, page 10 .
Remove wheel.
Remove suspension strut -arrows-.
Insert wood block between underbody -arrow A- and rear up‐
per control arm -arrow B-.
Wood block is needed to press wheel bearing housing down.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
162 Rep. Gr.42 - Rear Suspension
