43 – Self-Leveling Suspension
1 Specifications
⇒ “1.1 Fastener Tightening Specifications”, page 208
1.1 Fastener Tightening Specifications
Component Fastener Size Nm
Air Supply Unit Bracket Bolt - 20
Air Supply Unit Upper to Lower Part Bolt - 5
Body Acceleration Sensor Bolt - 8
Compressor Unit and Solenoid Valve Block Bracket
1
Bolt - 9
Bolt - 20
Nut - 9
Connector Piece in Solenoid Valve Block - 3
Connector Piece in Residual Pressure Retaining Valve - 5
Connector Piece in Pressure Reservoir - 5
Connector Piece in Line Connector (Pressure Reservoir T-Piece) - 3
Solenoid Valve Block Bracket Bolt - 9
Solenoid Valve Block to Bracket Bolt - 4
•
1
For bolt tightening clarification, refer to
⇒ “4.4 Air Supply Unit and Solenoid Valve Block Overview”, page 225 and see items
-19, 20, 21, 22 and 24-
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
208 Rep. Gr.43 - Self-Leveling Suspension
