5.5 Crossmember, Removing and Installing
Removing
– Remove subframe, refer to
⇒ “2.2 Subframe, Removing and Installing”, page 125 .
– Remove left and right suspension strut -arrows- and remove
crossmember.
Installing
– Install subframe ⇒ page 125 .
– Install the suspension strut on the crossmember and tighten
to 60 Nm.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
5. Coil Spring Suspension Strut and Crossmember 167
