10 - Rear Bonded Rubber Bushing, Rear
❑ Hydraulic support.
❑ Replace, refer to ⇒ “2.4 Subframe Bonded Rubber Bushing, Replacing”, page 129 .
❑ Installed position, refer to ⇒ Fig. ““Installation Location of Rear Bonded Rubber Bushing”“ , page 132 .
11 - Bolt
❑ 1 Nm
12 - Right Connecting Link
Note
The aluminum coupling rod has
been replaced with a steel one. Do
not install both types together.
13 - Stabilizer Bar
❑ Removing and Installing, refer to ⇒ “2.5 Stabilizer Bar, Removing and Installing”, page 133 .
14 - Stabilizer Bar Bearing
❑ Removing and Installing, refer to ⇒ “2.5 Stabilizer Bar, Removing and Installing”, page 133 .
❑ Installed position, refer to ⇒ “2.5 Stabilizer Bar, Removing and Installing”, page 133 .
15 - Bolt
❑ 50 Nm
16 - Clamp
17 - Left Connecting Link
Note
The aluminum coupling rod has
been replaced with a steel one. Do
not install both types together.
18 - Self-Locking Nut
❑ 100 Nm
❑ Always replace if removed.
19 - Stabilizer Bar Bearing
❑ Removing and Installing, refer to ⇒ “2.5 Stabilizer Bar, Removing and Installing”, page 133 .
❑ Installed position, refer to ⇒ “2.5 Stabilizer Bar, Removing and Installing”, page 133 .
20 - Expanding Rivet
21 - Bolt
❑ 120 Nm + 180°
❑ Always replace if removed.
22 - Stone Chip Protection
23 - Stone Chip Protection
24 - Bolt
❑ 1 Nm
2.2 Subframe, Removing and Installing
Special tools and workshop equipment required
♦ Brake Pedal Actuator - VAG1869/2-
♦ Air Line Insert Tool - T10212-
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
2. Subframe, Stabilizer Bar, Coupling Rod and Stone Deflector 125
