– With vehicles with air suspension, place vehicle on hoist, refer
to ⇒ “4 Positioning Vehicle on Hoist and Wheels”, page 10 .
Caution
• The Hose Clamps - Up To 25mm - 3094- must not be se‐
cured on return hose in check valve area. Otherwise,
check valve will be damaged.
• The check valve is in the return hose between the cambers
-A arrows- or between hose clamps -B arrows-.
Check Valve in Return Hose
– Clamp the intake hose and the return line on the reservoir us‐
ing Hose Clamps - Up To 25mm - 3094- .
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
294 Rep. Gr.48 - Steering
