Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Remove screws -2-.
Remove bracket upward and out between bumper and bump‐
er cover.
Installing
Install in reverse order of removal. Note the following:
Note
Studs in bracket are preset. If necessary, correct adjustment.
Place the Adaptive Cruise Control Sensor - G550- on a soft,
clean cloth.
Measure Dimension -a- of All Studs.
Dimension -a- must be 43 mm.
Insert bracket and tighten bolts.
Tightening specification, refer to
⇒ “6.1 Adaptive Cruise Control Sensor G550 Overview ”,
page 256 .
Install the Adaptive Cruise Control Sensor - G550- and care‐
fully push the mounts onto the stud bolts inside the sensor.
Install front bumper cover license plate holder and tighten
screws, refer to ⇒ Rep. Gr. 63 .
Calibrate the adaptive cruise control, refer to
⇒ “6.4 Adjustment Procedure Using ACC Setting Device
VAS6190 ”, page 259 .
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
6. Adaptive Cruise Control 269
