♦ Adapter - V.A.G 1402/4-
♦ Power Steering Test Unit - Adapter Hose - VAG1402/6-
Test Prerequisites
• Sealing of system
• Hoses/lines are not kinked or constricted
Checking
– With vehicles with air suspension, place vehicle on hoist, refer
to ⇒ page 10 .
– Remove the fuel filter -1- from the bracket -2- with the lines still
connected.
Caution
• The Hose Clamps - Up To 25mm - 3094- must not be se‐
cured on return hose in check valve area. Otherwise,
check valve will be damaged.
• The check valve is in the return hose between the cambers
-A arrows- or between hose clamps -B arrows-.
Audi Q7 2007 ➤
Suspension, Wheels, Steering - Edition 01.2014
354 Rep. Gr.48 - Steering
