119R5910032 /00 Freya
Image 7–82
5. Enter a name (reference 4).
Note: List of files already available in the projector is displayed in this window. Directly click on
this list allows you to reuse all or part of an already existing file name.
6. Click save (reference 5).
Note: If the name enter in the previous step already exists, a confirmation window is displayed
to confirm that you want to overwrite the file.
From version 1.2 or higher, number of files created and added to the 3D files list is different if Disable 3D
option is checked or not:
• if Disable 3D option is checked, one new file with name defined in step 5 is added to the 3D files list.
• if Disable 3D option is unchecked, 4 files are added to the 3D files list with names based on the name
defined in step 5 and a suffix relative to different frame rates available (e.g. RealD, RealD_48, RealD_
60 and RealD_auto).
For more information about the 3D file management, see “About 3D file”, page 115.
7.5.3 3D file editor
About this chapter
This chapter contains all the necessary information to use 3D file editor, the Web Communicator page used to
create or modify 3D files.
7.5.3.1 3D Test pattern
What can be done?
With the 3D test pattern, it is possible to test the complete setup in combination with an external polarizer
system, or active polarity glasses. The output frequency of the test pattern can be entered so that the
simulation of the input signal is completely covered for the used polarizer system or polarity glasses.
Image 7–83 3D test pattern
1 Left eye (Green field with white L)
2 Right eye (Magenta field)
Configuration - Projector
