R5910032 /00 Freya40
Image 3–5
4. Pull the HDD out of its slot.
Image 3–6
To install an HDD, see the following procedure: “Removing a HDD from the ICMP-X”, page 39.
3.5 Installing a HDD into the ICMP
This procedure assumes that the HDD slot of the ICMP is empty. If not, see procedure “Removing a
HDD from the ICMP-X”, page 39.
CAUTION: Always use a new empty spare part HDD approved by Barco to replace a malfunction
HDD. Do not use a HDD from another ICMP HDD set.
CAUTION: Always make sure that all HDDs in the ICMP HDD set have the same storage capacity.
See label on top of the HDD to know the storage capacity.
How to install a HDD ?
1. Ensure that the projector is switched off.
2. Prepare the HDD for insertion by moving the latch towards the left and push the unlock button to open the
handle.
ICMP-X
