R5910032 /00 Freya52
Image 4–14
The entire list is displayed again. Nothing is filtered.
4.8 Dashboard
About dashboard
At any time you can display dashboard to obtain status of Series 4 projectors connected on local network.
For each projector displayed on dashboard you have:
• the Auditorium name and IP address (reference 1).
• a slight overview of the projector status (reference 2):
- Light Source status (on-off).
- Dowser status (open-closed).
- Name of last macro activated.
- Test pattern status to know if test pattern is activated or not (on-off).
• a shortcut (reference 3) to launch a new Web Communicator instance dedicated to the targeted projector.
Image 4–15
How to display/close dashboard
1. In the menu bar, click on dashboard shortcut (reference 1).
Web Communicator – Graphical User Interface (GUI)
