R5910032 /00 Freya106
3. Select one of the following calibration options:
• Calibrate and return to mid position allows the lens to return to the middle position once the lens has
reached the reference point.
• Calibrate and return to original position allows the lens to return to the position before the calibration
once the lens has reached the reference point.
4. Click Start.
The calibration will start. A message will display the status of the calibration.
Image 7–60
5. After a while, the calibration will end and the page will automatically refresh.
The result of the calibration will be displayed in the calibration table (both failure and success).
7.4 Lens position
7.4.1 About Lens position
Location & access
Menu: Configuration > Projector > Lens position
Level: Administrator, Service technician
Overview
This panel allows to manage lens position files. These files contain zoom, shift and focus information. This
files must be created during projector installation and apply before each playout via a macro.
Configuration - Projector
