253R5910032 /00 Freya
The following options are possible:
• Default: default channel configuration as standard channel mapping. These mapping is only changed
in rare occasions or for troubleshooting reasons.
• Auro: channel configuration for the Auro standard.
• AuroMax: channel configuration for the AuroMax standard.
• Custom: channels can be configured by the customer.
2. Click and drag the desired label on to the desired channel (reference 1 and 2).
Image 13–15
3. Continue until all channels get a label.
4. Click Save button to save the audio channel configuration (reference 3.
Click Discard button to undo all changes (reference 4).
5. To delete a label from a channel, click on the delete button (reference 5)
Configuration - Media server
