307R5910032 /00 Freya
Overview of the ICMP-X settings:
Global setting
Description
Default value
Auditorium name Name of the auditorium displayed on
the user interface (front end application)
Auditorium
Host name Name assigned to the ICMP to identify
the device in the theater network
Not deleted nor modified when restoring
settings
IP address Parameters that define the network
interface
The network parameters are not deleted
after restoring settings but the DHCP
parameter is enabled.
User setting Description
Default value
User list The list of users and their access levels
to the ICMP functionalities
Admin → USER_ADMINISTRATOR
show → USER_SHOW_MANAGER
st →
Server setting Description
Default value
Server list The list of servers, remote directories
and libraries where the contents are
stored
Set to blank (empty)
Player setting Description
Default value
Audio delay (ms) Audio delay is used to correct the
synchronization between sound and
0
Audio output frequency
(kHz)
Allows set the sound for the audio
output
48000
Video output resolution Allows set the video resolution of the
ICMP (2K or 4K)
Auto
Audio setting Description
Default value of audio channel label
AES1 AES output 1 CH01, L
AES2 AES output 2 CH02, R
AES3 AES output 3 CH03, C
AES4 AES output 4 CH04, LFE
AES5 AES output 5 CH05, Ls
AES6 AES output 6 CH06, Rs
AES7 AES output 7 CH07, HI
AES8 AES output 8 CH08, VI-N
AES9 AES output 9 CH09, Lc
AES10 AES output 10 CH10, Rc
AES11 AES output 11 CH11, Lrs
AES12 AES output 12 CH12, Rrs
AES13 AES output 13 CH13, DBOX
AES14 AES output 14 CH14, Sync
AES15 AES output 15 CH15
AES16 AES output 16 CH16
Maintenance
