Display and operating elements
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
106
of 346
4.4
4.4.5 Setting the IP address with address switches
EtherCAT
®
CoE
EtherCAT
®
SoE
BM5XXX-XXXX-XXXX-01XX
BM5XXX-XXXX-XXXX-07XX
VARAN BM5XXX-XXXX-XXXX-02XX
POWERLINK
®
BM5XXX-XXXX-XXXX-04XX
EtherNet/IP
®
BM5XXX-XXXX-XX07-00XX
Modbus/TCP BM5XXX-XXXX-XX08-00XX
IP-Address
S1 to S4
The IP address of the controller consists of 32 bits or 4 bytes (e.g. 192.168.125.203).
Both of the first bytes are set with the base address (192.168.) at the factory. Both of the
last bytes are set by means of the address switches S1, S2, S3 and S4. In the process,
S1 and S2 as well as S3 and S4 each represent an 8 bit value.
The IP address 192.168.0.0 or 192.168.100.0 is not permitted/reserved.
For information on changing the base address, refer to the parameter manual.
Switch setting up
Switch setting down
