Accessories and spare parts
Instruction handbook b maXX 5000
Document No.: 5.09021.16
263
of 328
11
11.2.3 BM5043, BM5044
m Semiconductor fuses aR (device) BM504X, type NH (for CE only)
Bussmann 000 80A/690V: 170M1566 U 100A/690V: 170M1567 U
125A/690V: 170M1568 U
00 80A/1000V: 170M2680 100A/1000V: 170M2681
1 80A/690V: 170M3811 U 100A/690V: 170M3812 U
125A/690V: 170M3813 U 160A/690V: 170M3814 U
Class J: DFJ-80 U for
BM5043 Class J: DFJ-150 U for BM5044
SIBA 1 125A/690V: 2021120/125A
Siemens 000 80A/690V: 3NE8 720-1 U 100A/690V: 3NE8 721-1 U
125A/690V: 3NE8 722-1 U
00 80A/690V: 3NE8 020-1 U 100A/690V: 3NE8 021-1 U
125A/690V: 3NE8 022-1 U 160A/690V: 3NE8 024-1 U
0 80A/1000V: 3NE4 120 U 100A/1000V: 3NE4 121 U
125A/1000V: 3NE4 122 U
1 100A/1000V: 3NE3 221 U 125A/1000V: 3NE3 222 U
160A/1000V: 3NE3 224 U
80A/690V: 3NC2 280, 22x58 for BM5043
Size
11.2.4 BM5173, BM5174
m Semiconductor fuses aR (device) BM5173, BM5174, type NH (for CE only)
Bussmann 1 100A/690V: 170M3812 U 125A/690V: 170M3813 U
160A/690V: 170M3814 U
Class J: DFJ-100 for BM5173 Class J: DFJ-150 for BM5174
SIBA 1 100A/690V: 2021120/100A 125A/690V: 2021120/125A
160A/690V: 2021120/160A
Siemens 0 100A/1000V: 3NE4 121 U 125A/1000V: 3NE4 122 U
1 100A/1000V: 3NE3 221 U 125A/1000V: 3NE3 222 U
160A/1000V: 3NE3 224 U
Size
