8.4.4 POWERLINK
®
.
Type code b maXX 5000 with POWERLINK
®
:
BM5XXX-XXXX-XXXX-04XX-
b maXX 5000 devices can communicate with a POWERLINK
®
Managing Node via the
fieldbus connection POWERLINK
®
.
X3 and X4 on the front side of the device are the RJ45 connections for POWERLINK
®
(also see ZFront side of active mains rectifier BM51XX– on page 173 and ZFront side
axis units BM53XX– on page 175).
Mounting and in-
stallation.
The mounting/installation consists of the following steps:
1 De-energize the b maXX 5000 device
2 Set the b maXX 5000 IP-address,
see ZSetting the IP address with address switches– as from page 100
3 Connect b maXX 5000 with Ethernet-connection cables.
n Please, observe an EMC-compatible laying of the Ethernet connection cables!
n The following cables were released for use by Baumüller:
Ethernet-connection cable;
Further information see ZEtherCAT
®
,
VARAN, POWERLINK
®
cable– on page 249.
Commissioning. The following preconditions must be fulfilled before commissioning:
1b maXX 5000 with POWERLINK
®
is installed correctly.
n Ethernet-connection cables are wired correctly.
2 The control cabinet is properly locked and all safety devices are operating.
3 The b maXX 5000 device is ready-to-use.
Address switch By means of the address switches S3 and S4 the last byte of the IP-address is set
(Refer to settings ZSetting the IP address with address switches– as from page 100).
IP address 192.168.100.0 is not allowed.
Further information about the setting possibilities of the POWERLINK
®
Controlled Node
see „Application Manual“.
Parameters The parameter settings determine the behavior of the POWERLINK
®
Controlled Node in
operation. Parameters are set via the software ProDrive.
1 Start ProDrive
2 Click on „Project Tree“.
3 Communication settings using ProDrive
n Project Tree: Configuration/Fieldbus Slave
(refer also Parameter manual b maXX 5000)
m set Synchronization to „On“
m SYNC time = Fieldbus cycle time = POWERLINK
®
cycle time = 500 µs to 8 ms
This setting is not necessary if using the POWERLINK
®
profile and the POWER-
LINK
®
Managing Node sets a valid value in object 0x1006 „Communication cycle
period“.
