Fieldbus communication
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
234
of 346
8.4
8.4.5 EtherNet/IP
®
.
Type code b maXX 5000 with add-on module EtherNet/IP
®
:
BM5XXX-XXXX-XX07-00XX-
Devices bmaXX5000 communicate with the add-on modujle EtherNet/IP
®
with an
EtherNet/IP
®
scanner.
X1 and X2 on the add-on module are the RJ45 connections for the EtherNet/IP
®
(also see ZAdd-on module EtherNet/IP®– on page 197.
Mounting and
installation.
The mounting/installation consists of the following steps:
1 De-energize the b maXX 5000 device
2 Set the bmaXX5000 IP-address,
see ZSetting the IP address with address switches– as from page 106
3 Connect b maXX 5000 with Ethernet-connection cables.
n Please, observe an EMC-compatible laying of the Ethernet connection cables!
n The following cables were released for use by Baumüller:
Ethernet-connection cable;
Further information see ZEtherCAT
®
, VARAN, POWERLINK
®
, EtherNet/IP
®
, Mod-
bus
®
cable– on page 265.
Commissioning. The following preconditions must be fulfilled before commissioning:
1 b maXX 5000 with EtherNet/IP
®
is installed correctly.
n Ethernet-connection cables are wired correctly.
2 The control cabinet is properly locked and all safety devices are operating.
3 The bmaXX5000 device is ready-to-use.
Address switch By means of the address switches S1 to S4 the IP-address is set
(Refer to settings ZSetting the IP address with address switches– as from page 106).
Parameters The parameter settings determine the behavior of the EtherNet/IP
®
in operation.
Parameters are set with the software ProDrive.
1 Start ProDrive
2 Click on „Project Tree“.
3 Communication settings with ProDrive
n Project Tree: Configuration/Fieldbus Slave
(refer also Parameter manual b maXX 5000)
m set Synchronization to „On“
m SYNC time = Fieldbus cycle time = EtherNet/IP
®
cycle time = 500 µs to 8 ms
This setting is not necessary if a valid value is set in byte 0 of the EtherNet/IP
®
scanner.
