Troubleshooting and Fault correction
Instruction handbook b maXX 5000
Document No.: 5.09021.16
233
of 328
10
Cyclic set value
transmission to
the fieldbus
The active mains rectifier is able to exchange cyclic data with the master control. If this
data exchange is not within a defined time period, the device will generate the errors „Ac
-
tual values are not received in time“ or „No data available at the moment“.
Temperature of
device interior
This monitoring function checks the temperature in the interior of the device.
m If the temperature is higher than the warning threshold, then the controller generates a
warning.
m If the temperature is too high, then the pulses are inhibited immediately.
Heat sink
temperature
This monitoring function checks the temperature of the heat sink.
m If the temperature is higher than the warning threshold, then the controller generates a
warning.
m If the temperature is too high, then the pulses are inhibited immediately.
Signal bus At axis units all power units are linked together via a so called „signal bus“. The bus sig-
nals can be polled and set by every client device, including the mains rectifier unit.
The mains active rectifier can report to the axis units via this bus
m Ready-to-operate for drive
This way, the individual axes can react to this signal.
Signal bus - Mains rectifier unit ready-to-operate
Shows when the mains rectifier unit is in the „ready-to-operate“ state. This signal is gen-
erated after reaching the value U
DC link actual
= U
DC link set value
- 10 V.
In case of power supply errors or power supply failure, the ready-to-operate signal is can-
celed again. The axis units react to this with error state.
Signal bus - Malfunction
The „Malfunction“ signal is an input for mains rectifier unit and active mains rectifier unit.
This signal is not evaluated by the active mains rectifier at the moment.
