Baumuller b maXX 5000 User Manual

Accessories and spare parts
Instruction handbook b maXX 5000
Document No.: 5.09021.16
271
of 328
11
11.4.2 Selection of the mains filter
IT systems
NOTE!
EMC limit values are not defined for trans
ient emission in power systems without
grounded star point (IT system). A fault state (motor ground fault) can lead to the
damage of the mains filter.
It is not recommended to use mains filter in IT
systems. The transient emission can
exceed the limit values of category C3.
TN systems
I
rated AC
at
Type Part
nu
mber
Use with devices
operation at
rated power
1)
Use with devices
operation at
cyclic overload
1)
40°C 50°C
17,5 A 16 A BFN 3-1 - 0016 - 001 314278 BM5031
32,9 A 30 A BFN 3-1 - 0030 - 001 314279 BM5032
82,2 A 75 A BFN 3-1 - 0075 - 001 314282 BM5043
100 A 100 A BFN 3-1 - 0100 - 001 314283 BM5043
142,4 A 130 A BFN 3-1 - 0130 - 001 314284 BM5044
87 A 80 A Schaffner FN 3120H-80-35 BM5173
150 A 150 A EPCOS B84143A0150R410 437618 BM5174
295 A LGF FFU 3x295AB-SBM 463278 BM519X
Based on the application, use an mains filter from the following table.
1)
With lower output at continuous operation, filters with lower rated currents can be used too. Filters with higher
rated currents are necessary in case of using the overload capacity of the mains inverters cyclically. If over-
current is only needed one-time and non-recurrently (once per hour, for a maximum of 60 s), then the filters
suggested for
operation at the rated power are sufficient.
