Monitoring
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
226
of 346
8.3
8.3 Monitoring
8.3.1 Monitoring BM50XX
The controller unit monitors the device during operation. If the controller unit detects a
state that deviates from the normal operation condition, the device generates an error
message.
Error message If the controller unit detects that the device is not working error-free, then this is shown
via the LEDs H1 to H4 (see ZDisplay and operating elements– as from page 96 for de-
vices without safety function and see ZD.4 LED display BM5030 with safety function– as
from page 326 for devices with safety function).
For further information see ZTroubleshooting and Fault correction– as from page 243.
8.3.2 Monitoring BM51XX, BM53XX
The controller unit monitors the device during operation. If the controller unit detects a
state that deviates from the normal operation condition, the device either generates a
warning or an error message.
Warning If the controller unit detects an operating condition that exceeds a warning threshold, a
corresponding warning is shown on the display or, respectively, controller. The most im-
portant warning message (Current limit reached) is also shown by the device through the
LED H13 or H23 (see ZDisplay and operating elements– as from page 96).
Error message If the controller unit detects that the device is not working error-free, then this is shown
via the LED H14 or H24 (see ZDisplay and operating elements– as from page 96). A cor-
responding error code will continue to be shown on the display and/or a controller can
read out the error code on the device.
For further information see ZTroubleshooting and Fault correction– as from page 243.
