Error handling
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
254
of 346
10.4
For further information on the subjects of error messages and error numbers, see „Pa-
rameter manual bmaXX 5000„.
10.4 Error handling
10.4.1 Error acknowledgment of BM50XX
If the red error LEDs H1 to H4 light up, then at least one error has been detected.
All error messages are reset by error acknowledgment. Individual acknowledgment of er-
rors is not possible. An acknowledgment delete all errors, if deletion was possible on ac-
count of the error cause.
Errors can be acknowledged via the digital input X1:4.
Thereby a rising edge (low to high) is evaluated. The high level has to be applied at least
100 ms.
BM50XX-XXX0 For further information, see ZFigure 70– on page 150 and ZFigure 80– on page 164.
BM50XX-XXX1 For further information, see ZFigure 71– on page 151 and ZFigure 80– on page 164.
NOTE!
The device is shipped with predefined error reactions. With regard to the error mes-
sages identified with „depending on the setting“ in the „Reaction“ column, the device's
error reaction can be adjusted. Error messages that, due to safety reasons, have an
immediate pulse inhibit as a consequence, may not be changed.
NOTE!
When using devices BM5XXX-XXX1 all error messages can be reset with
Power supply off
Power supply on additionally.
