Mounting of toroidal cores
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
126
of 346
6.4
6.4.2 Mounting the toroidal cores
Carry out mounting as follows:
1 Keep suitable fastening components readily available.
2 Mount the toroidal cores
3 Lay the mains cable through the toroidal cores, see ZInstallation procedure– as from
page 148.
Figure 57: Toroidal cores mounted
Bolts 6 x M8
Washers 6 x (8.4 x 25)
