Operating conditions
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
46
of 346
3.3
3.3 Operating conditions
3.3.1 Requirements for power supply / mains supply system
Power supply mains BM50XX - XTXX / - XRXX
6)
BM51XX - XTXX / - XRXX
6)
Industrial system, with direct or low
impedance grounded neutral point
(TN system or TT system)
BM50XX - XIXX / - XSXX Industrial system with not grounded or with
high impedance grounded neutral point
(IT system)
in addition TN or TT system
BM50XX - XGXX / - XWXX Industrial system, with direct or low
impedance grounded junction of phases
(grounded delta wye)
in addition TN system, TT or IT system
Inductance
(sum of mains inductance
and mains choke inductance)
BM50XX - XT.../XI.../XG...
BM51XX - XT.../XI.../XG...
u
k min
= 2.4 %
u
k max
= 4 %
Mains inductance
7)
BM503X - XR.../XS.../XW...
BM504X - XR.../XS.../XW...
u
k min
= 0.5 %
Rated power supply voltage/frequency
1) 2)
(U
AC
) device
3x400V
50/60 Hz
Power supply voltage
Absolute minimum
1) 2)
(U
AC
) device
Absolute maximum
1) 2)
(U
AC
) device
BM50XX 3 x 207 V
/ 50/60 Hz
3 x 528 V / 50/60 Hz
BM51XX 3 x 360 V
/ 50/60 Hz
3 x 528 V / 50/60 Hz
Absolute frequency minimum
5)
Absolute frequency maximum
5)
47 Hz
63 Hz
Overvoltage category
EN 61800-5-1, chapter 4.3.6
III
Harmonic frequencies (power supply voltage)
EN 61800-3, chapter 5.2.1, class 3
THD
U
b 12 %
Power supply voltage asymmetry
EN 61000-2-4, table 1, Class 3
Max. 3 %
Commutation notches
EN 61800-3, chapter 5.2.1, class 3
Notch depth < 40 %,
area < 250 % x degree
Voltage drops
EN 61800-3:2004 and A1:2012 10 % to 80 %
1)
Voltage changes/fluctuation
EN 61200-2-4, class 3
+/-10 %
+10 % to -15 %, for a duration of b 1min
Max. short circuit current power supply
4)
50 000 A
Prospective short circuit current according EN61800-5-1 BM503X, BM504X, BM517X 5 kA
BM507X, BM519X 18 kA
Control voltage
3)
(U
DC
)
according to EN 61131-2:2008
+ 24V -15% / +20%
