Instruction handbook b maXX 5000
Document No.: 5.09021.16
11ACCESSORIES AND SPARE PARTS
Accessories/spare parts for devices of the b maXX series are listed in this appendix.
Product management is happy to handle any queries and suggestions on accessory
parts.
11.1 Cabling
11.1.1 Device - mains cabling
Device Cross-section
1)
Maximum length
2)
Connection to device
3)
BM503X 4 x 4 to 25 mm² Power supply to mains filter:
user-defined
Line filter to power choke /
device: max.
30 cm
Flexible cable with wire end ferrule
(screw terminal)
BM504X
BM517X
4 x 16 to 50 mm²
(AWG 6 - 0)
Flexible cable with cable lug
(
current bars)
BM519X
1)
Possible cross-section.
For UL-compliant machines/systems, U
L-certified cabling must be used.
2)
The length of the cable between the mains filter and mains supply is irrelevant to adhering to the EMC directive.
3)
The type of routing is user-defined.
