11.1.9 Encoder cables
Selection of the
encoder cables
The trailing cables are suitable for mobile deployment, for example in mobile cable han-
dlers. In addition, the cable sheath can be used in
environments with acids and bases
(e.g. coolant).
With servo motors using the Resolver encode
r system, the temperature sensor is con-
nected to the device via the encoder cable. Addition
al technical data, connector assign-
ments, application notes and Part numbers can
be found in the motor documentation.
Cables pre-assembled - trailing
type; CE UL/CSA, Halogen-free, according to IEC 60754-1, Sili-
cone-free, FCKW-free, RoHS compliant, a
dditional lengths upon request.
Length
Resolver Encoder with
HI
PERFACE
®
Sine-/square wave
incremental encoder
Part No. Part No. Part No.
speedtec
®
speedtec
®
speedtec
®
1 m 429914 448746 429958 448761 430015 448777
2 m 429915 448747 429959 448762 430016 448778
3 m 429916 448748 429960 448763 430017 448779
5 m 429917 448749 429961 448764 430018 448780
7 m 429918 448750 429962 448765 430019 448781
10 m 429919 448751 429963 448766 430020 448782
15 m 429920 448752 429964 448767 430021 448783
20 m 429921 448753 429965 448768 430022 448784
25 m 429922 448754 429966 448769 430023 448785
30 m 429923 448755 429967 448770 430024 448786
35 m 429924 448756 429968 448772 430025 448787
40 m 429925 448757 429969 448773 430026 448788
50 m 429926 448758 429970 448774 430027 448789
75 m 429927 448759 429971 448775 430028 448790
