Installation

Instruction handbook bmaXX 5000

Document No.: 5.09021.19

213

of 346

Motor brake/

temperature

Single axis unit BM537X

Assignment pre-assembled Baumüller cable see motor documentation.

X206/X207

X206 Pin No. Assignment

1 +24V motor brake

Supply voltage for

motor brake

2 M24V motor brake

3 +24V motor brake

4 M24V motor brake

X207 Pin No. Assignment

1 Motor brake 1-

Motor 1

motor temperature and

motor brake

2 Response, motor brake 1-

3 Motor temperature 1-

4 Motor brake 1+

5 Response, motor brake 1+

6 Motor temperature 1+

X207, X208 Pin No. Level

Feedback signal

motor brake

2, 5 Low: 0 V ... 10 V

High: 17.5 V ... 30 V
