Mounting
Instruction handbook bmaXX 5000
Document No.: 5.09021.19
117
of 346
6
6.2.1 Drilling pattern
Use the drilling pattern to make the necessary drill holes/cutout sections.
How to determine the required space in the control cabinet, see ZDimensions– as from
page 29.
Tolerance
specifications
For air-cooled
versions:
For BM50XX-S, BM51XX-S, BM53XX-S only!
*: Relative tolerance of discretionary divisions: ±0.1 mm
Figure 47: Drilling pattern with mounting rail for BM50XX-S, BM53XX-S, BM51XX-S
NOTE!
Consider the minimum clearances for cooling when making the drill holes.
All dimensions in millimeters [mm].
Further notes see ZDimensions– as from page 29 and ZCooling– as from page 58.
Drill hole dimensioning ±0.2 mm
Dimensioning openings +1.0 mm
Relative tolerance of discretionary divisions ±0.1 mm
