Mounting instructions
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
120
of 346
6.3
6.3.1 Mounting with mounting rail
After attaching the mounting rail, push the device from below beneath the upper fastening
bolts (1). Then, tilt the device on the mounting plate (2) and slide onto the mounting rail
(3). Finally, tighten the upper fastening and grounding bolts (4).
Figure 50: Mounting instructions for the BM51XX and BM53XX, with mounting rail
1)
Number n depends on the length of the mounting rail
Device BM50XX-S BM507X-S
BM517X-S
BM519X-S BM532X-S
BM533X-S
A - screws 2 x M5 3 x M5 8 x M5 2 x M5
B - washers 2 x (5.3 x 10) 3 x (5.3 x 10) 4 x (5.3 x 10) 2 x (5.3 x 10)
C - screws n x M5
1)
D - Mounting rail 1000 mm Refer to Accessories and Spare Parts ZMounting rail– as from page 304
