Cabling
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
242
of 328
11.1
11.1.2 Cable device - motor
NOTE
The total parasitic cable capacitance wire/sh
ielding of the motor cables within the
system must not exceed 30 nF. Additional measurements have to be taken (e.g. the
us
e of DC link filters) in case of cable capacitances higher than 30 nF.
Device Cross-section
1)
Maximum length
2) 3)
Connection to device
BM532X 4 x (0.2 to 6 mm²)
(AWG 24 -10)
Dependent on the cross-section used:
4 x 1.5 to 2.5 mm² (AWG 16 -12): 100 m
4 x 4 to 25 mm² (AWG 10 -3): 60 m
4 x 35 mm² (AWG 1): 50 m
 4 x
50 mm² (AWG 1/0): 15 m
Motor connector
Flexible cable with wire end ferrule
BM533X 4 x (4 to 16 mm²)
(AWG 20 - 4)
Flexible cable with wire end ferrule
(cla
mp terminal)
Flexible cable with/without wire
en
d ferrule (clamp terminal)
BM537X 4 x (16 to 50 mm²)
(AWG 6 - 0)
Cable lug max. width: 20 mm
1)
Possible cross-section.
Use a shielded Baumüller cable, optical shield cover
ing > 85%, no single-wires.
For UL-compliant machines/systems, UL-certified cabling must be used.
2)
Only using Baumüller cables with this maximum length and Baumüller mains filters, it can be assumed that the threshold limit value of
the EMC product standard EN 61800-3 is complied with.
3)
If n parallel-routed motor cabling is used, then the maximum length must be reduced by a factor of 1/n.
