Baumuller b maXX 5000 User Manual

Cabling
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
250
of 328
11.1
11.1.7 Accessories - CANopen
®
.
m CANopen
®
-connection cables:
Type Model Length [m] Part No.
BM4-CAN-K-31-01 RJ45-connector, 
male sub D con-
nector
1 346568
BM4-CAN-K-31-02 2 on request
BM4-CAN-K-31-03 3 346571
BM4-CAN-K-31-05 / 10 5 / 10 on request
BM4-CAN-K-32-01 RJ45-connector, 
sub D female
1 346572
BM4-CAN-K-32-02 2 on request
BM4-CAN-K-32-03 3 346573
BM4-CAN-K-32-05 / 10 5 on request
BM4-CAN-K-33-01 RJ45-connector, 
RJ45-connector
1 346577
BM4-CAN-K-33-02 2 on request
BM4-CAN-K-33-03 3 on request
BM4-CAN-K-33-05 5 on request
BM4-CAN-K-33-10 10 on request
m T
erminated connector RJ45 
(Termination connector CAN, RJ45 with pin assignm
ent according to CIA-standard,
120 , 0.25 W)
Type Part No.
BM4-CAN-T01 346408
11.1.8 Service interface cable
Type Length [m] Part number
BM5-K-USB-018 1.8 430279
PC side interface USB 2.0
Driver installation is done with the installation of ProDrive
