Baumuller b maXX 5000 - BM503 X-A Dimensions

Dimensions
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
30
of 346
3.1
Figure 4: BM503X-A dimensions
*: Observe minimum clearance.
Please follow the notes for mounting and ZCooling– on
page 58.
395
373
357,5
100 *
100 *
75
210
BM503X-A
READY
H1
H2
H3
H4
PHASE FAILURE
OVERTEMPERATURE
DC-LINK ERROR
b maXX
5000
309
26
68
