Electrical connections
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
166
of 328
7.14
7.14.9 Connection data
NOTE!
Description of BM5030 with safety function BM5
030-XX2X-...
see ZC.6.1 Con
nection data of BM5030 with safety function– as from page 311.
NOTE!
To ensure sufficient current load capacity of the connections, adhere to the specified
torques!
Connection
cross section
Connection
method
Torque Load capacity
Power supply 
system
1U1, 1V1, 1W1
BM503X-
XX0X
Max. 25 mm² Screw terminal Min. 4.0 Nm
Max. 4.5 Nm
Refer to
ZFuses– as fro
m
page 261
BM504X
BM
517X
Max. 50 mm² Screw terminal Min. 6.0 Nm
Max. 8.0 Nm
BM519X Cable lug for M10 Min. 30 Nm
Max. 40 Nm
PE power supply 
system
BM503X-
XX0X
Min. 10 mm² Cable lug for M5 Min. 2.2 Nm
Max. 3.0 Nm
-
BM504X
BM
517X
½ power supply
connection cross
section, 
Min. 16 mm²
Cable lug for M6 Min. 3.0 Nm
Max. 4.0 Nm
-
BM519X Cable lug for M10 Min. 30 Nm
Max. 40 Nm
PE device BM53XX Min. 10 mm² Cable lug for M5 Min. 2.2 Nm
Max. 3.0 Nm
-
Torque Max load
c
apacity of the
bar
DC link
1C1 and 1D1
all other
devices
DC link bar Min. 2.2 Nm
Max. 3.0 Nm
130 A
BM519X Min. 4,0 Nm
Max. 4,8 Nm
300 A
