Operating conditions
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
44
of 328
3.3
3.3 Operating conditions
3.3.1 Requirements for power supply / mains supply system
Power supply mains BM50XX - XTXX / - XRXX
6)
BM51XX - XTXX / - XRXX
6)
Industrial system, with direct or low
impedance grounded neutral point
(TN system or TT system)
BM50XX - XIXX /
- XSXX Industrial system with not grounded or with
high impedance grounded neutral point
(IT system)
in addition TN or TT system
BM50XX - XGXX /
- XWXX Industrial system, with direct or low
impedance grounded junction of phases
(grounded delta wye)
in addition TN system, TT or IT system
Inductance 
(sum of mains inductance
and mains chok
e inductance)
BM50XX - XT...
/XI.../XG...
BM51XX - XT...
/XI.../XG...
u
k min
= 2.4 %
u
k max
= 4 %
Mains inductance
7)
BM503X - XR.../XS.../XW...
BM504X - XR...
/XS.../XW...
u
k min
= 0.5 %
Rated power supply voltage/frequency
1) 2)
(U
AC
) device
3 x 400 V
50
/60 Hz
Power supply voltage

Absolute minimum
1) 2)
(U
AC
) device
Absolute maximum
1) 2)
(U
AC
) device
BM50XX 3 x 207 V
/ 50/60 Hz
3 x 528 V / 50/60 Hz
BM51XX 3 x 360 V
/ 50/60 Hz
3 x 528 V / 50/60 Hz
Absolute frequency minimum
5)
Absolute frequency maximum
5)
47 Hz
63 Hz
Overvoltage category
EN 61800-5-1, chapter 4.3.6
III
Harmonic frequencies (power supply voltage)
EN 61800-3, chapter 5.2.1, class 3
THD
U
b 12 %
Power supply voltage asymmetry
EN 61000-2-4, table 1, Class 3
Max. 3 %
Commutation notches
EN 61800-3, chapter 5.2.1, class 3
Notch depth < 40 %,
area < 250 % x degree
Voltage drops
EN 61800-3:2004 and A1:2012 10 % to 80 %
1)
Voltage changes/fluctuation
EN 61200-2-4, class 3
+/-10 %
+10 % to -15 %, for a duration of b 1 min
Max. short circuit current power supply
4)
50 000 A
Control voltage
3)
(U
DC
)
according to EN 61131-2:2008
+ 24 V -15 % / +20 %
