DANGER!
Risk of fatal injury due to high leakage current!
The cross-section of the protective ground conductor must be at least 10 mm²
(EN 61800-5-1, Chapter 4.3.5.5.2).
BFN 3-1- ... -001 0007 0016 0030 0042 0056 0075 0100 0130
Max. power supply voltage 3 x 480 V
AC
+10%, 50/60 Hz
Rated current (at T
B
= 40°C) 7.6A 17.5A 33A 46A 70A 82A 109A 142A
Rated current (at T
B
= 50°C) 7A 16A 30A 42A 56A 75A 100A 130A
Peak current 1.5 x I
N
for < 1 min per hour
Max. voltage
Outer conductor/GND
Neutral point of the outer conductor/GND
305 V
AC
0V
Max. test voltage line to line
line to case
2.1 kV
DC
for 2 s at 25 °C
2.7 kV
DC
for 2 s at 25 °C
Maximum connection cross-section 4
mm²
4
mm²
10
mm²
10
mm²
16
mm²
25
mm²
50
mm²
50
mm²
Power loss (typical) 4W 8W 12 W 15W 18W 24W 24W 30W
Harmonic frequencies (mains voltage) THD
U
< 10%
Protection rating IP 20
Weight 0.6 kg 1.0 kg 1.3 kg 1.6 kg 1.9 kg 2.6 kg 4.0 kg 4.2 kg
BFN 3-1-... -001 0250 0320
Max. input supply voltage 3 x 480 V
AC
+10 %, 50/60 Hz
Rated current
(at T
B
= 50 °C)
250A 320A
Peak current
(at T
B
= 50 °C)
4 x I
N
when switching on
1.5 x I
N
for < 1 min / once per hour
Test voltage line - line: 2150 V
DC
/ 2 s
line - housing: 2700 V
DC
/ 2 s
Connection bolt M10 bar with hole
 11mm
PE: bolt M12
Power loss (typical) 60 W 40 W
Protection class IP 00
