Line filters
Instruction handbook bmaXX 5000
Document No.: 5.09021.19 Baumüller Nürnberg GmbH
290
of 346
11.4
Figure 127: Dimensions HOWCORE NFI-20
HOWCORE
NFI-020
EPCOS
B84143A0150R410
LGF
FFU 3x295AB-SBM
Max. power supply voltage 3 x 480 V
AC
+10 %, 50/60 Hz
Rated current (at T
B
= 40°C) 20A 150A 295A
Peak current (at T
B
= 40°) 1.5 x I
N
for < 3 min per hour
1.5 x I
N
for < 60 s per hour
Max. voltage
outer conductor/GND
neutral point of the outer conductor/GND
305 V
AC
0V
Max. test voltage at 25 °C
line to line
line to case
2.1 kV
DC
at 25 °C for 2 s
2.2 kV
DC
for 2 s
2.7 kV
DC
for 2 s
2.1 kV
DC
for 2 s
2.7 kV
DC
for 2 s
Maximum connection cross-section 95 mm²
Harmonic frequencies (mains voltage) THD
U
< 10 %
Protection rating IP 20
Weight 13.5 kg
