Baumuller b maXX 5000 User Manual

Installation
Instruction handbook b maXX 5000
Document No.: 5.09021.16
133
of 328
7
7.9 Shielding plan side-by-side mounted system
The shielding of the motor cable as well as of the motor temperature cable must be con-
nected electrically with the mounting plate or with shield sheet (see ZShielding c
onnec-
tion with shield sheet– on pa
ge 134).
NOTE!
Baumüller Nürnberg GmbH recommends the shielding connection with shield sheet.
NOTE!
Pay attention to strain relief for all cables!
7.9.1 Shielding connection mounting plate
Establish a large-area contact between the shield and the conductive and grounded
mounting plate by means of a conductive clamp.
Refer to ZConnecting the shield– a
s from page 135.
