Dimensional
drawing
Figure 129: Dimensions of choke BM50XX
Connection
diagram
Figure 130: Connection diagram of choke BM50XX
0450/0550 368386 451 550 360 260 320 310 140 11 15 50 5 for M12
0530/0650 368387 533 650 360 260 320 310 140 11 15 50 5 for M12
0615/0750 368388 615 750 420 285 375 370 151 11 15 60 5 for M12
0750/0920 368389 754 920 420 285 375 370 151 11 15 60 5 for M12
0900/1100 368390 902 1100 420 285 380 370 166 11 15 60 10 for M12
BK3- Part No. I
AC
[A]
I
DC
[A]
a
[mm]
b
[mm]
c
[mm]
d
[mm]
e
[mm]
f  g
[mm]
Flat connector
Cu terminals
[mm  mm]
U V
W
X
Y
Z
PE
PE U X V Y W Z
