WARNING!
Risk of injury due to insufficient qual
ifications!
Inevitably, when operating this electrical device
, certain parts of this device are ener-
gized with hazardous voltage. Improper handling can lead to significant personal in-
jury and material damage.
Therefore:
m Only
qualified personnel may work on this device!
Operating concept
Instruction handbook b maXX 5000
Document No.: 5.09021.16 Baumüller Nürnberg GmbH
204
of 328
8.1
8.1 Operating concept
After the device has been commissioned it is parameterized (i. e. adapted to the applica-
tion). Once parameterization has been comple
ted, the device can be operated with one
of the two following signal inputs:
m p
ulse enable
m quick stop (opt
ion)
8.1.1 Release signals
These signals must have a signal level of 24 V (DC) and be available via the terminals
(ZCon
nections on the front side– as from page 171).
Pulse enable During operation, the „pulse enable“ signal mu
st be continuously generated in order for
the device to provide output. A running motor will come to a standstill if the signal is
switched to 0 V.
Quick stop Only switch off the „quick stop“ signal if the system / th
e device must be stopped as quick-
ly as possible. The reaction can be a
djusted (see the parameter manual)
During operation, the „quick stop“ signal must b
e continuously provided in order for the
device to provide output.
Exactly which digital input can be assessed as a
quick stop signal can be parameterized.
(Refer to the parameter manual b maXX 50
00 5.09022)
