Mounting
Instruction handbook bmaXX 5000
Document No.: 5.09021.19
123
of 346
6
m DC link bar
Observe the correct mounting of the DC link bar. There should no mechanical stress
affect to the drill hole.
Figure 54: Mounting of the DC link bar
6.3.4 Demounting
WRONG CORRECT
NOTE!
The DC link bar must not overlap the first or last fixing bolt of the rack system.
Cut the DC link bar therefore.
NOTE!
The yellow cover plate can be removed when mounting/demounting air-cooled devic-
es and there is not enough space above the device (min. 15 cm) for lifting up the
cover.
The yellow cover plate must be removed when replacing the cold plate devices, al-
ways.
