Accessories and spare parts
Instruction handbook b maXX 5000
Document No.: 5.09021.16
279
of 328
11
11.5.2 Power chokes for BM51XX
NOTE
Only the power choke mentioned below is
permitted for use with BM51XX devices.
BM5173
Marking Inductance Part number
BL-3-060-000 1 mH 388168
This power chokes are specified for operation at 400 V/50 Hz bzw. 480 V/60 Hz.
Figure 122: Power choke BM5173
A B C D E F G Connection Mounting
260 300 306 110 140 9x13
8,5 Bar with hole M8 M8
m Tr
amag
UL approval
This chokes are design-tested in accordance with UL
(e.g. UL1561) and signified by the
„ú“ “ symbol.
Name Inductance Part number
BL-3-060-001 1 mH 415096
